Description
Intuitive Touchscreen Interface: Amateur Radio First! The touchscreen interface offers innovative, fast, and smooth operation for adjusting various functions and editing memories.
Slanted Top Controller: The slanted top display faces the operator and is designed to maximize screen visibility. The built-in, high-efficiency oval speaker delivers clear, easy-to-hear sound. An external speaker and an electronic keyer can be connected to the controller.
D-STAR DV Mode Operation: The IC-7100 provides D-STAR DV mode, digital voice, and low-speed data communication. Linking D-STAR repeaters over the internet enables long-distance communication with clear, intelligible modulated digital audio. D-STAR: Intelligent Digital Technology for Amateur Radio
DSP IF Features: The latest 32-bit floating-point DSP supports numerous digital processing functions such as digital IF, dual PBT, and manual notch filters. Of course, these high-end digital processing features work on all amateur radio bands, from HF to the 70 cm band.
Optional suction cup mounting base, MBF-1
The optional MBF-1 is a suction cup mounting base for easy installation in your vehicle. The MBA-1 mobile mounting bracket is also required.
(Radio supplied with IC-OPC2253 splitter cable kit)
Other Features
• Built-in SD card slot for voice storage and data cloning
• Dual DSP chip for versatile digital processing performance
• Built-in RTTY demodulator and decoder
• Multifunction meter
• Graphical SWR display
• DSP controller, RF voice compressor
• Total 505 memory channels
• Voice recording and playback functions
• High-frequency stability of ±0.5 ppm
• Optional RS-BA1 IP control software
Frequency Coverage*1 (Unit: MHz)
Receiver 0.030–199.999*2 400.000–470.000*2
Transmit
1.800–1.999 3.500–3.999 5,255–5,405*2
7,000–7,300 10,100–10,150 14,000–14,350
18,068–18,168 21,000–21,450 24,890–24,990
28,000–29,700 50,000–54,000 144,000 144,000–
148,000 430,000–450,000
*1 Displays the US version. This varies by version.
*2 Some frequency bands are not guaranteed.
USB, LSB, CW, RTTY, AM, FM,
WFM (prescription only)
Number of channels
505 memory channels (495 regular, 4 calling, 6 scanning edges)
700 (D-STAR repeater channels)
SO-239 antenna connectors x2 (one for HF/50 MHz and VHF/UHF bands, 50Ω)
Operating temperature range: -10°C to +60°C +14°F to +140°F
Frequency Stability ±0.5 ppm (+0°C to +50°C)
Power Supply Required 13.8 VDC ±15%
Current Consumption (at 13.8 VDC) Tx Max Power 22 A / Rx Max Audio/Standby 1.5/1.2 A
Dimensions (W×H×D, projections not included)
RF Unit 167×58×225 mm
Controller 165×64×78.5 mm
Weight (approx.) RF Unit 2.3 kg
Controller 0.5 kg
TRANSMITTER
Output Power (at 13.8 VDC)
HF/50 MHz 144 MHz 430/440 MHz
SSB/CW/RTTY/FM/DV 2–100 W 2–50 W 1–35 W
AM 1–40 W – –
Spurious Emissions Less than –50 dB (HF bands)
Less than –63 dB (50 MHz)
Less than –60 dB (144/430 MHz)
Carrier Suppression More than 50 dB
Unwanted Sideband Suppression More than 50 dB
RECEIVER
Intermediate Frequencies
SSB/CW/AM/FM
WFM
124.487 MHz, 455 kHz, 36 kHz
134.732 MHz, 10.700 MHz
Sensitivity
0.5–1.8 MHz 1.8–29.9 MHz 50–54 MHz 144/430 MHz
SSB/CW/RTTY – 0.16 μV 0.13 μV 0.11 μV
AM 13 μV 2 μV 1 μV 1 μV
FM 0.5 μV (28–29.7 MHz) 0.25 μV 0.18 μV
DV 1 μV (28–29.7 MHz) 0.63 μV 0.35 μV
WFM – – 10 μV (76–108 MHz)
Selectivity
More than less than
SSB (BW=2.4 kHz, high) 2.4 kHz/–6 dB 3.6 kHz/–60 dB
CW (BW=500 Hz, peak) 500 Hz/–6 dB 900 Hz/–60 dB
RTTY (BW=350 Hz) 360 Hz/–6 dB 650 Hz/–60 dB
AM (BW=6 kHz) 6.0 kHz/–6 dB 15 kHz/–60 dB
FM (BW=15 kHz) 12 kHz/–6 dB 20 kHz/–60 dB
DV (12.5 kHz spacing) –50 dB
Image and Noise Rejection Ratio: Greater than 70 dB (HF bands)
More than 65 dB (50/144/430 MHz)
(except IF point 144 MHz)
Audio Output Power (at 13.8 VDC): More than 2.0 W (10% distortion, 8Ω load)
Supplied Accessories:
Microphone
HM-198 IC-HM151 Optional touch-tone microphone, see below
Power cable
CW Keyer
Replacement fuses
OPC-223 splitter cable
13-pin DIN cable
USB cable
Multi-band operation, all modes at your fingertips!
Icom changed the way amateur radio operators viewed HF mobile communication in 1995 with the introduction of the IC-706. Since then, Icom Mobile HF radios have become the go-to choice for high-performance HF mobile radios. At Tokyo Hamfair 2012, Icom once again revolutionized mobile HF communications with the introduction of the IC-7100. It offers ease of use thanks to fingertip control via an intuitive touchscreen interface and the power of a 32-bit IF DSP.
Output Power
100 W HF/50 MHz
50 W 144 MHz
35 W
